Features

• Water Pump Use
• Rooftop and off-Grid Design
• High Module Efficiency
• 5 Year Warranty for Material Processing

Comprehensive Certifications

• IEC 61215. IEC 61730 i.V.
• IEC TS 62941: Terrestrial Photovoltaic (PV) Modules - Guidelines for increased confidence in PV Module Design qualification and type approval.

Mechanical Parameters

• Cell Orientation: 72(24x3)
• Junction Box: IP65, 1 bypass-diodes
• Output Cable: 750mm
• Glass: 3.2mm solar glass
• Frame: Anodized aluminium
• Weight: 5.5kg
• Dimensions (mm): 904 x 580 x 25

Electrical characteristics

• Module Type: 100WP
• Testing Condition: STC
• Maximum Power: 100
• Open circuit voltage (V): 49.0
• Short circuit current (A): 2.58
• Voltage at Maximum Power (V): 40.6
• Current at Maximum Power (A): 2.47
• Module Efficiency: 19.36%.

Operating characteristics

• Operational Temp: minus 40°C to 85°C.
• Power Output Tolerance: 0±5Wp.
• Maximum System Voltage: 1000V DC.
• Maximum Series Fuse Rating: 10A.
• Nominal Operating Cell Temperature: 48°C ±2°C.

Temperature Ratings STC

• Temperature Coefficient of is ( )0.04%/K.
• Temperature Coefficient of Voc: (-)0.30%/K.
• Temperature Coefficient of Pmax: (-)0.40%/K.

Please note that panel dimensions and specifications are subject to change. Please double check with us that they are correct at time of purchase.
