Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | CBMC E4 24DC/1-10A NO |
| Approvals | EAC, UL Listed, cUL Listed, UL Recognized, cULus Listed |
| Color | Light Grey Ral 7035 |
| Contact Type | without electrical isolation |
| Depth | 98 mm |
| Dielectric Strength | max. 35 V DC (Load circuit) |
| Efficiency | > 99 % |
| Fuse Type | electronic |
| Height | 90 mm |
| IP Rating | IP20 |
| Mounting Type | DIN rail: 35 mm |
| Output Voltage | 12 VDC, 5 VDC |
| Power Dissipation | 9 W (Nominal operation) |
| Primary Type | Circuit Breaker |
| Protection Class | III |
| Shop By | Factory Choice |
| Stripping Length | 10 mm |
| Type | DIN rail module, one-piece |
| UPC Code | 4055626149356 |
| Width | 36 mm |
